Recommended Products

•

  £1,291.99 inc VAT

  Add to cart

  H&R Deep Coilover Kit for VW Golf IV Platform: 60-120mm

  H&R Coilovers, H&R Deep Coilovers Golf Mk4 / Mk5 / Mk6

  £1,291.99 inc VAT

•

  £750.00 inc VAT

  Add to cart

  MTS Technik Street Coilover Kit Volkswagen Golf Mk4 + Bora ( Audi TT 8N, A3 8L, Seat Leon Mk1, Skoda Octavia ) 2WD

  Choose Top Mount Option: With Camber Adj. Top Mount, Chasis: 4WD, Suspension: Sport

  £750.00 inc VAT

•

  £1,695.00 – £2,020.00 inc VAT

  Select options

  Gepfeffert KW Coilover VW Mk4 Audi A38L TT8N Beetle Bora Seat Leon 1M – 2WD

  Audi, A3 / S3 / RS3, KW Gepfeffert Coilover Suspension, Seat Leon KW Gepfeffert Suspension, Audi A3 S3 RS3 KW Gepfeffert Suspension, Golf Mk4 / Mk5 / Mk6 Gepfeffert Coilovers

  Gepfeffert KW Coilover suspension 2WD (low version)

  Fits the following models:

  • VW Golf IV / Beetle / Bora
  • Audi TT 8N / A3 8L
  • Seat Leon 1M

  For more stability or ride comfort. With adjustable rebound damping.

  The KW coilover suspension variant 2 "inox-line" is the suspension for the experienced sports driver who wants to make adjustments to the setup in addition to lowering the vehicle individually. The individually adjustable rebound damping ensures better connection on fast road sections and easier vehicle control. In addition, rolling comfort on bad roads can be significantly influenced with adjusted rebound damping.

  The gepfeffert.com® V2 coilover suspension made by KW

  With the KW coilover suspension variant 2 "inox-line", you can influence the handling and comfort yourself as an experienced sports driver through the individually adjustable rebound tuning. The 16 exact clicks allow you to tune the KW dampers tighter or more comfortable without affecting the bottom valve of the compression stage.

  Technical information: V2

  - damping technology adjustable in the rebound stage in 16 exact clicks

  - Stainless steel technology inox-line

  - Individual, stepless lowering

  - tested adjustment range

  - ready-to-install complete solution

  - High quality components for long service life

  - complete documentation for easy use

  Technical information: V3

  - damping technology adjustable in the rebound stage in 16 exact clicks

  - damping technology adjustable in the compression stage in 12 exact clicks

  - Stainless steel technology inox-line

  - Individual, stepless lowering

  - tested adjustment range

  - ready-to-install complete solution

  - High quality components for long service life

  - komplette Dokumentation für einfache Anwendung

    Note: The picture may differ from the delivered product

  KW automotive GmbH and / or StillStatic Limited accepts no liability for any damage that may occur as a result of non-compliance with the above points.

  £1,695.00 – £2,020.00 inc VAT

•

  £519.00 – £819.00 inc VAT

  Select options

  MTS Technik Street Coilover Kit Volkswagen Golf Mk4 + Bora ( Audi TT 8N, A3 8L, Seat Leon Mk1, Skoda Octavia ) 2WD

  MTS Suspension, VW Mk4 Golf MTS Coilover Kits

  Coilover Kit Volkswagen Golf IV

  Coilover Kit MTS Technik for Volkswagen Golf IV and Similar ( Check List ), lowering the front axle between 30 - 60 mm, and rear between 25 - 50 mm. Dedicated for the years of: 08/97 - 12/07, for the engine version: 1.4 16V / 1.6 / 1.6 16V / 1.6FSI / 1.8 / 1.8T GTI / 2.0 / 2.3 V5 / 1.9SDI / 1.9TDI.

  Series:	comfort
  Max. Axle Load FA:	-1020 kg
  Max. Axle Load RA:	-1020 kg
  Lowering FA:	30 - 60 mm
  Lowering RA:	25 - 50 mm
  Camber / top mount FA:	yes
  Camber / top mount RA:	no
  Coilover Main Spring (Front):	Spring rate (50 N/mm)
  Coilover Helper Spring (Front):	Spring rate (20 N/mm)
  Coilover Main Spring (Rear):	Spring rate (28 - 55 N/mm)
  TUV Certificate:	no
  Download information brochure:	Download information brochure
  Download installation manual:	Download installation manual

    2 year warranty with no mileage limit to confirm high quality. Suspension components characterized by increased corrosion resistance and made of the highest quality materials. The use of twin-tube technology guarantees stable shock absorber performance. Pressurized gas presses the hydraulic fluid, eliminating the "foaming" effect of the oil (an undesirable and typical for oil shock absorbers phenomenon), which means higher efficiency for continuous, intensive work. Specially selected type of thread and a wide range of suspension adjustment allows optimal setting of the car height. Double zinc plated steel shock absorbers as well as anodized aluminum adjusters and caps to ensure increased corrosion resistance. Coilover springs made by Eibach, the world leader in the sport springs industry.

  3 - Front and rear axle height adjustable (threaded shock absorber housing on the front, dampers, springs and height adjustable elements on the rear).

  5 - Stabilizer bars may need to be changed with longer ones if lowering more than 40mm.

  6 - If the right drive shaft diameter of more than 42 mm, the maximum lowering mentioned in the catalogue is reduced by 15 mm.

  8 - Not for 4x4.

  21 - If the vehicle is equipped with a stock sport suspension, the lowering mentioned in this catalogue will be relatively lower.

  24 - During the installation of suspension set the clearance between tire/rim and suspension strut shall be checked. The minimum allowed gap is 5mm (0,2 inch). Otherwise use certificated wheel spacers.

  73 - For easier height adjustment, we recommend removing the rear adjustment, changing the position of the spring plate and reinstalling the adjustment on the car.

  Audi TT 8N Roadster1.8T10/99 - 06/06

  Skoda Octavia I Kombi1.4 / 1.4 16V / 1.6 / 1.8 / 1.8T / 2.0 / 1.9SDI / 1.9TDI07/98 - 12/10

  Volkswagen Bora Kombi1.4 16V / 1.6 / 1.6 16V / 1.6FSI / 1.8 / 1.8T / 2.0 / 2.3 V5 / 1.9SDI / 1.9TDI05/99 - 05/05

  Volkswagen Golf IV1.4 16V / 1.6 / 1.6 16V / 1.6FSI / 1.8 / 1.8T GTI / 2.0 / 2.3 V5 / 1.9SDI / 1.9TDI08/97 - 12/07

  Seat Leon I (1M1)1.4 16V / 1.6 / 1.6 16V / 1.8 20V / 1.8T / 1.9SDI / 1.9TDI11/99 - 06/06

  Seat Toledo II (1M2)1.4 16V / 1.6 / 1.6 16V / 1.8 20V / 2.3 V5 / 2.3 V5 20V / 1.9TDI10/98 - 05/06

  Skoda Octavia I Sedan1.4 / 1.4 16V / 1.6 / 1.8 / 1.8T / 2.0 / 1.9SDI / 1.9TDI09/96 - 12/10

  Volkswagen Golf IV Kombi1.4 16V / 1.6 / 1.6 16V / 1.6FSI / 1.8 / 2.0 / 2.3 V5 / 1.9SDI / 1.9TDI05/99 - 06/06

  Volkswagen New Beetle1.4 / 1.6 / 1.8T / 2.0 / 2.3 V5 / 2.5 / 1.9TDI01/98 - 11/10

  VolkswagenNew Beetle Cabriolet1.4 / 1.6 / 1.8T / 2.0 / 2.5 / 1.9TDI09/02 - 12/11

  Volkswagen Bora1.4 16V / 1.6 / 1.6 16V / 1.6FSI / 1.8 / 1.8T / 2.0 / 2.3 V5 / 1.9SDI / 1.9TDI10/98 - 12/13

  Audi TT 8N Coupe1.8T10/98 - 06/06

  AudiA3 8L1.6 / 1.8 / 1.8T / 1.9TDI09/96 - 09/06

  £519.00 – £819.00 inc VAT
